TECHANICAL DATA
PACKING
10 pcs per poly bag – 50 bags per carton.
Carton specification: 49×40 ×27
SECURITY
Serial number can be laser marked on the Cap. Locking mechanism is trapped by a security cap which is ultrasonically welded onto the seal body.
SPECIFICATIONS
- Material pc+pp
- Marks: Numbering, logo, bar code.
- Printing: Laser print or hot stamping
- Color: Red, Blue, Yellow, Green, White Or Customers Required
RECOMMENDED APPLICATIONS
Meters, Cabinets, Valves, Fuel tanks, Etc.
TENSILE
Complied with C-TPAT & ISO17712
ASSEMBLING
Simple, no tools or assembly required. Pass the wire through the two holes in the outer part, and then turn the handle clockwise to achieve the perfect closure. Removable by cable cutter.
SEALING WIRE
Customised wire length.
The wire is made with stainless steel (coated / non-coated) having diameter 0.5 to 0.8mm.
